RIGID AND SOFT PVC MIXIN
The SHR turbomixers is used for rigid and soft PVC have shown themselves to be extremely efficient in the thermoplastic materials transformation industry. When good quality material must be combined with high hourly throughput, this turbomixer is the ideal solution. A perfect mix can only be achieved by using extremely high quality tools. Each manufacturing sector has different characteristics and needs which is why Chiyu provides a wide range of mixing tools. (more than 50 types).The SHR turbomixers is used for rigid and soft PVC have shown themselves to be extremely efficient in the thermoplastic materials transformation industry. When good quality material must be combined with high hourly throughput, this turbomixer is the ideal solution. A perfect mix can only be achieved by using extremely high quality tools. Each manufacturing sector has different characteristics and needs which is why Chiyu provides a wide range of mixing tools. (more than 50 types).
FEATURES
MIXING VESSEL
- Internal surfaces in contact with the material are made of stainless steel.
- Double or triple insulated jacket for the circulation of water or oil.
MIXING TOOL
- Made of stainless steel, with axial and radial mixing effect, designed to optimize distribution of the hot material on the cooling surfaces.
DISCHARGE
- Openable discharge outlet
- Double discharge outlet
LID
- Can be supplied in various configurations; it can be opened vertically thanks to a pneumatic cylinder operated lifting system.
- Intrinsic safety opening system with lead screw type mechanic or automatic actuator.
- Safety device only allowing the lid to be opened after the mixer has stopped moving
TEMPERATURE CONTROL
- By means of thermocouple located at the side of the mixing vessel to control operating and safety temperatures.
Technincal data (SHR Turbomixer)
Type | Total capaicty litres | Weight per batch kgs | Motor power KW |
|---|
SHR200 | 200 | 90 | 45 |
SHR250 | 250 | 110 | 55 |
SHR300 | 300 | 140 | 75 |
SHR400 | 400 | 180 | 90 |
SHR500 | 500 | 220 | 110 |
SHR600 | 600 | 260 | 132 |
SHR700 | 700 | 310 | 160 |
SHR800 | 800 | 360 | 200 |
SHR1000 | 1000 | 450 | 250 |
SHR1500 | 1500 | 675 | 355 |
SHR2000 | 2000 | 900 | 560 |
RLW Cooler Introduction
The RLW cooler stands out for its great and proven cooling efficiency, allowing excellent throughput and high standards of quality. Material can be stored at lower temperature because it is cooled not only superficially but also at the core and thus has no thermal inertia that will cause packing.
Cleaning and maintenance times are reduced to a minimum thanks to total opening of the lid, which allows easy access to all internal parts. Applicable to any type of turbomixer and can be built in special versions and/or with larger capacities to meet specific customer needs.
Technincal data (RLW Cooler)
Type | Total capacity | Motor power KW(Standard) | Motor power KW(Boost) |
|---|
RLW600 | 600 | 11 | 18.5 |
RLW800 | 800 | 18.5 | 22 |
RLW1000 | 1000 | 18.5 | 22 |
RLW1500 | 1500 | 22 | 37 |
RLW1800 | 1800 | 22 | 37 |
RLW2000 | 2000 | 37 | 45 |
RLW3000 | 3000 | 45 | 55 |
RLW4500 | 4500 | 45 | 55 |
RLW5500 | 5500 | 55 | 75 |
RLW6500 | 6500 | 75 | 90 |
RLW8500 | 8500 | 75 | 90 |
FAQ
Q: What materials are SHR turbomixers suitable for?
A: The SHR turbomixer is specially designed for mixing and processing rigid and soft PVC materials, and is widely applicable to various thermoplastic material processing industries with high capacity and high-precision mixing requirements.
Q: What are the core structural advantages of the mixer?
A: It adopts full stainless steel material contact structure, double/triple insulation jacket, axial and radial composite mixing tools. It is equipped with safe pneumatic lifting lid, multi-type discharge outlets and high-precision thermocouple temperature control system for stable and efficient operation.
Q: What is the advantage of the supporting RLW cooler?
A: The RLW cooler realizes synchronous cooling of material surface and core, eliminating thermal inertia and material packing problems. It features high cooling efficiency, large throughput, and minimized cleaning and maintenance workload.
Q: Is the equipment customizable for production demands?
A: Yes. The cooler supports customized special versions and large-capacity models, and the mixer is equipped with over 50 types of mixing tools to meet diverse production needs of different industries.
Q: What safety protection does the mixer have?
A: It is equipped with intrinsic safety opening system and interlock safety device, which only allows the lid to be opened after the mixer stops running, effectively ensuring operation safety.
Q: What specifications are available for the equipment?
A: SHR mixers cover 200L-2000L specifications with matched 600L-8500L RLW coolers, with complete power and capacity models to meet different batch production demands.
